On-Metal PCB UHF RFID Tag NXP® UCODE® 8
$3.00 – $317.00Price range: $3.00 through $317.00
This tag is fully compatible with the ISO/IEC 18000-6C and EPC Global Gen2v2 protocol. The tag can be easily installed using screws or adhesive. It’s extremely compact at just 10 × 4 mm, making it ideal for precision instruments and equipment, and for tracking and managing metal assets such as metal components.
Description
Features
Frequency Band
865-868MHz (EU) | UHF 902-928 MHz(US)
Chip Type
NXP® UCODE® 8
International Standard
ISO/IEC 18000-6C, EPC Global Gen2v2
EPC Memory
128 bits
TID Memory
96 bits
High-Temperature Resistant
100 °C
Specifications
Physical Specifications
Material: PCB
Tag Size: 10×4mm(Hole Diameter:⌀2mm)
Tag Thickness: 2 mm without IC bump, 3 mm with IC bump
Tag Weight: 0.5 g
Tag Color: Black, Red, Blue, Green, White
Mounting Methods: Adhesive, Screw
Chip Characteristics
Chip Manufacturer: NXP®
Chip Type: NXP® UCODE® 8
EPC memory: 128 bits
User memory: 0 bits
TID memory: 96 bits
Write Endurance: 100,000 times
Data Retention: Up to 20 years
(Perma) LOCK™: Support
Kill Command: Support
EAS Tag Alternative Function: Support
Tag Performance Optimization: Support
Autocorrect Memory Protection: Support
Authenticity Certification: Support
Technical Parameters
Operating Frequency: 865-868 MHz(EU) | 902-928 MHz(US)
Communication Protocol:
ISO/IEC 18000-6C, EPC Global Gen 2v2
Applicable Surface: Metal Surfaces
Read Range(Fix Reader): 1.05 m on metal(FCC), 1.45 m on metal(ETSI)
Read Range(Handheld Reader): 0.7 m on metal(FCC), 0.8 m on metal(ETSI)
Additional Information
Operating Environment:
-40°C ~ 100°C, 98% Non-condensing
Storage Environment:
18°C ~ 28°C, 40% ~ 60% RH
Thermal Endurance (Non-operating):
-40°C ~ 150°C, 98% Non-condensing
Download & Support AZT-U8-OMFR4-1004
Reading Range Under Different Frequency(US)
Tag Power Under Different Frequency(US)
Reading Range Under Different Frequency(EU)
Tag Power Under Different Frequency(EU)
