This tag is made of FR-4 material with an IP68 rating and is fully compatible with the ISO/IEC 18000-6C (EPC Global Gen2v2) protocol. The tag can be easily installed using screws, rivets, or adhesive. Its high-temperature resistance makes it ideal for use in various harsh environments, making it perfect for asset tracking and management across different applications.
Material: FR-4 Tag Size: 13 × 7 mm Tag Thickness: 3 mm without IC bump Tag Weight: 0.7 g Tag Color: Black IP Rating: IP68 Mounting Methods: Adhesive, Screw, Rivet, Magnet, 3M Adhesive Backing, Glue Dispensing, Embedding Customization: Printing LOGO, Barcode, Serial Number, Encoding, Designing
Chip Characteristics
Chip Manufacturer:NXP® Chip Type: NXP® UCODE® 8 Data Retention: Up to 20 years EPC memory: 128 bits User memory: 0 bits TID memory: 96 bits (Perma) LOCK™: Support Write Endurance: 100,000 times EAS Tag Altemative Function: Support Tag Performance Optimization: Support Kill Command: Support Autocorrect Memory Protection: Support Authenticity Certification: Support
Technical Parameters
Operating Frequency: 865-868 MHz(EU)/902-928 MHz(US) Communication Protocol: ISO/IEC 18000-6C, EPC Global Gen 2v2 Applicable Surface: Metal Surfaces Read Range(Fix Reader): 1.5m on 15×2 cm metal, 7m on 14×14 cm metal Read Range(Handheld Reader): 4 m on 15×2 cm metal, 1.5 m on 14×14 cm metal
Operated by ACCUZ® Industries, a leading RFID hardware manufacturer for over a decade, RFIDTag™ is committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and rigorous quality control processes ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Led by seasoned professionals, our team is at the forefront of RFID technology innovation. We specialize in developing custom solutions and delivering the latest products designed to meet your specific business needs, ensuring you benefit from the most advanced technology available.
EFFICIENT & RELIABILITY
We offer reliable global shipping, with one of the most extensive stocks in the market ensuring that in-stock items are delivered within 1-3 business days across North America, Europe, and the Asia Pacific. Our proven track record and substantial inventory guarantee your satisfaction with each order.
EN
ES
JA
On-Metal UHF RFID PCB Tag NXP® UCODE® 8
$3.00 – $323.00Price range: $3.00 through $323.00
This tag is made of FR-4 material with an IP68 rating and is fully compatible with the ISO/IEC 18000-6C (EPC Global Gen2v2) protocol. The tag can be easily installed using screws, rivets, or adhesive. Its high-temperature resistance makes it ideal for use in various harsh environments, making it perfect for asset tracking and management across different applications.
Description
Features
Frequency Band
UHF 865-868 MHz/902-928 MHz(US)
Chip Type
NXP® UCODE® 8
International Standard
ISO/IEC 18000-6C, EPC Global Gen2v2
IP Rating
IP68
EPC Memory
128 bits
TID Memory
96 bits
Specifications
Physical Specifications
Material: FR-4
Tag Size: 13 × 7 mm
Tag Thickness: 3 mm without IC bump
Tag Weight: 0.7 g
Tag Color: Black
IP Rating: IP68
Mounting Methods: Adhesive, Screw, Rivet, Magnet, 3M Adhesive Backing, Glue Dispensing, Embedding
Customization: Printing LOGO, Barcode, Serial Number, Encoding, Designing
Chip Characteristics
Chip Manufacturer: NXP®
Chip Type: NXP® UCODE® 8
Data Retention: Up to 20 years
EPC memory: 128 bits
User memory: 0 bits
TID memory: 96 bits
(Perma) LOCK™: Support
Write Endurance: 100,000 times
EAS Tag Altemative Function: Support
Tag Performance Optimization: Support
Kill Command: Support
Autocorrect Memory Protection: Support
Authenticity Certification: Support
Technical Parameters
Operating Frequency: 865-868 MHz(EU)/902-928 MHz(US)
Communication Protocol:
ISO/IEC 18000-6C, EPC Global Gen 2v2
Applicable Surface: Metal Surfaces
Read Range(Fix Reader):
1.5m on 15×2 cm metal, 7m on 14×14 cm metal
Read Range(Handheld Reader):
4 m on 15×2 cm metal, 1.5 m on 14×14 cm metal
Additional Information
Thermal Endurance(Non-operating):
-40°C ~ 150°C, 98% Non-condensing
Operating Environment:
-40°C ~ 85°C, 98% Non-condensing
Storage Environment:
18°C ~ 28°C, 40% ~ 60% RH
Download & Support AZT-U8-OMFR4-1307
Reading Range
Tag Power
