On-metal RFID Tag for Industrial Use Monza® R6-P | 87×24mm
$5.00–$826.00Price range: $5.00 through $826.00
This industrial-grade polycarbonate RFID on-metal tag, powered by the Impinj® Monza® R6-P chip, delivers reliable long-range tracking (up to 9.8m) on metal surfaces. Designed for asset management in harsh environments, it is IP67-rated, 87×24mm in size, and suitable for containers, tools, and returnable packaging.
Material: Polycarbonate Tag Dimension: 87×24 mm; Thickness: 11 mm (Hole: D 5 mm) Net Weight: 19 g Tag Color: White (Black, Red, Blue, Green) IP Rating: IP67 Mounting Methods: Adhesive, Screw
Chip Characteristics
Chip Manufacturer:Impinj® Chip Type: Monza® R6-P Write Cycles: 100,000 cycles Data Retention: 50 years User Memory: 64 bits TID Memory: 96 bits EPC Memory: 128 bits Read Sensitivity: Up to -22 dBm Write Sensitivity: Up to -17 dBm
Technical Parameters
Operating Frequency: 840~940 MHz Communication Protocols: ISO/IEC 18000-6C, EPCglobal Gen2v2 Applicable Surface: Metal Surfaces Reading Range (Fix Reader): 9.8 m – (4 W, 36 dBm), On Metal 4.8 m – (4 W, 36 dBm), Off Metal Reading Range (Handheld Reader): 6 m – (1 W, 30 dBm), On Metal 2.8 m – (1 W, 30 dBm), Off Metal
Environmental Spec
Operating Limits: -30°C ~ 70°C Storage Environment: 18°C ~ 28°C Applications: Asset tracking, warehouse management, logistics, and equipment tracking in challenging in industrial conditions.
Operated by ACCUZ® Industries, a leading RFID hardware manufacturer for over a decade, RFIDTag™ is committed to delivering unparalleled quality at competitive prices. Our advanced production facilities and rigorous quality control processes ensure that every product meets the highest standards.
EXPERTISE & INNOVATION
Led by seasoned professionals, our team is at the forefront of RFID technology innovation. We specialize in developing custom solutions and delivering the latest products designed to meet your specific business needs, ensuring you benefit from the most advanced technology available.
EFFICIENT & RELIABILITY
We offer reliable global shipping, with one of the most extensive stocks in the market ensuring that in-stock items are delivered within 1-3 business days across North America, Europe, and the Asia Pacific. Our proven track record and substantial inventory guarantee your satisfaction with each order.
EN
ES
JA
On-metal RFID Tag for Industrial Use Monza® R6-P | 87×24mm
$5.00 – $826.00Price range: $5.00 through $826.00
This industrial-grade polycarbonate RFID on-metal tag, powered by the Impinj® Monza® R6-P chip, delivers reliable long-range tracking (up to 9.8m) on metal surfaces. Designed for asset management in harsh environments, it is IP67-rated, 87×24mm in size, and suitable for containers, tools, and returnable packaging.
Description
Features
Frequency Band
UHF 840~940 MHz
Chip Type
Impinj® Monza® R6-P
International Standard
ISO/IEC 18000-6C, EPCglobal Gen2v2
EPC memory
128 bits
User memory
64 bits
IP Rating
IP67
Specifications
Physical Specifications
Material: Polycarbonate
Tag Dimension: 87×24 mm; Thickness: 11 mm (Hole: D 5 mm)
Net Weight: 19 g
Tag Color: White (Black, Red, Blue, Green)
IP Rating: IP67
Mounting Methods: Adhesive, Screw
Chip Characteristics
Chip Manufacturer: Impinj®
Chip Type: Monza® R6-P
Write Cycles: 100,000 cycles
Data Retention: 50 years
User Memory: 64 bits
TID Memory: 96 bits
EPC Memory: 128 bits
Read Sensitivity: Up to -22 dBm
Write Sensitivity: Up to -17 dBm
Technical Parameters
Operating Frequency: 840~940 MHz
Communication Protocols: ISO/IEC 18000-6C, EPCglobal Gen2v2
Applicable Surface: Metal Surfaces
Reading Range (Fix Reader):
9.8 m – (4 W, 36 dBm), On Metal
4.8 m – (4 W, 36 dBm), Off Metal
Reading Range (Handheld Reader):
6 m – (1 W, 30 dBm), On Metal
2.8 m – (1 W, 30 dBm), Off Metal
Environmental Spec
Operating Limits: -30°C ~ 70°C
Storage Environment: 18°C ~ 28°C
Applications: Asset tracking, warehouse management, logistics, and equipment tracking in challenging in industrial conditions.
Download & Support AZ-R6P-OMPC-8724
Reading Range under different frequency
Tag Power under different frequency
