UHF 12-dBi RFID Antenna ISO 18000-6C
$154.00
The UHF RFID Antenna 12dBi delivers superior sensitivity and exceptional long-distance reading and writing capabilities. It supports high-volume tag identification with fast and secure data transmission. Rated IP67 for excellent waterproofing, this antenna is easy to install and ideal for smart transportation, logistics, warehouse and event management, production lines, smart retail, defense security, power asset, financial, and medical equipment management.
Description
Features
Frequency Band
UHF 860~960 MHz
International Standard
ISO/IEC 18000-6C, EPC Class 1 Gen 2
IP Rating
IP67
Gain Values
12 dBi
Wind resistance
60 m/s
Installation method
Pole-mounting
Specifications
Physical Specifications
Shell material: ABS
Dimensions: 445 x 445 x 30 mm
Weight: 2.66 kg
Radiation plate material: Aluminum
Interface Form: N female
IP rating: IP67
Installation
Installation: Pole-mounting
Diameter of support rod: 30-50 mm
Technical Parameters
Frequency: 865~868 MHz | 902~928 MHz
Protocol: ISO/IEC 18000-6C, EPC Class 1 Gen 2
Horizontal Angle: 40°
Vertical Angle: 38°
Polarization: Circular Polarization (right-handed)
Standing Wave Ratio: ≤ 1.3
Gain Values: 12 dBi
Antenna front-to-back ratio: ≥ 17dB
Characteristic impedance: 50Ω
Maximum input power: 20W
Environmental Spec
Operating Limits: -40°C ~ 60°C, DC grounding
Wind Resistance: 60 m/s
Reading Range H-side
Reading Range E-side
RFID Readers to Match ISO 18000-6C Compliant
UHF RFID 4-Port | 8-Port Reader AZF-M1
Cables to Connect 15m for 9 & 12 dBi
15-Meter Cable for UHF RFID Fixed Reader AZF-M1
